The three phase suction units are suitable to be installed on processing machines and production lines in the pharmaceutical, chemical and food industry. They are designed to suck small quantity of powders with a continuous use. They are available in version “BA” placed horizontally with visible motor or with frame and version “BAV”, set vertically always equipped with protective frame.
Both versions are available with motors from 0.37 kw up to 4 kw of power.
| Tension /Voltage | 3~ 230-400V/50Hz Volts |
| Power | 2.2 kW |
| Depression Max | 310 mbar |
| Max working depression | 200 mbar |
| Max Air Flow | 310 m³/h |
| Primary Filtering Surface | 0,70 m² |
| Absolute Filtering Surface | 3,1 m² |
| Container Capacity | 12 Lt |
| Product Inlet | Ø50 mm |
| Noise Level | 73 Dba |
| Overall Dimensions | 51x56x105h CM |
| Weight | 54 KG |
| Protection | 54 IP |
